The Dana 60 front axle is a heavy-duty component often found in heavy-duty trucks, military vehicles, and off-road builds. Knowing how to identify one is crucial for those working on these vehicles or sourcing parts. This guide provides several methods to help you confidently identify a Dana 60 front axle.

Visual Identification of a Dana 60 Front Axle

Several visual cues can help you quickly identify a Dana 60. However, remember that variations exist across different years and applications.

1. Axle Tube Diameter:

Significant Size: The most prominent feature is its substantial size. Dana 60 axle tubes have a significantly larger diameter than those found on lighter axles like Dana 44s or Ford 9-inch axles. Measure the diameter with a caliper for a precise measurement. A Dana 60 generally measures around 3 inches in diameter.

2. Third Member Housing:

Casting Numbers: Look for casting numbers on the differential housing (third member). These numbers often indicate the axle type and manufacturing date. These are usually found on the top or side of the differential housing. A common number to look for is "Dana 60." However, there might be other numbers indicating a specific application or variation.

3. Knuckle Design:

High-Pinion or Low-Pinion: Dana 60s come in both high-pinion and low-pinion configurations. High-pinion axles have the ring gear pinion positioned above the center line of the axle shafts. Low-pinion axles have the pinion below the center line. This impacts the axle's strength and ground clearance. Observe the pinion's location relative to the axle shafts.

4. Brake Caliper Mounting:

Position and Size: Pay attention to how the brake calipers are mounted. The size and placement of the caliper mounting points can vary between axle types.

5. U-Bolt Pattern:

Spacing and Configuration: The U-bolt pattern on the spring perches provides another distinguishing feature. Measure the distance between the U-bolt centers. While not always definitive, this measurement can help you differentiate between axle types.

Detailed Identification Methods

If visual inspection is inconclusive, consider these more precise methods:

1. Detailed Casting Number Research:

Online Databases: After locating the casting numbers, consult online databases and forums dedicated to identifying Dana axles. These resources often provide comprehensive information based on the casting numbers.

2. Measurement of Axle Shaft Diameter:

Precision Measurement: Use a caliper to accurately measure the axle shaft diameter. This provides additional confirmation, as the Dana 60 has large diameter axle shafts.

3. Component Analysis:

Gear Ratio and Ring & Pinion: By disassembling the third member, you can determine the gear ratio and the ring and pinion size. This information is specific to the Dana 60 and its variations. This is a more involved process requiring mechanical expertise.

Identifying Specific Applications

While the above methods help identify a Dana 60, pinpointing the specific application (e.g., Ford, Chevy, Jeep) requires further investigation. This often involves cross-referencing the casting numbers with online resources and vehicle-specific parts catalogs.

Remember safety precautions when working on or around heavy-duty vehicle components. Always use appropriate safety gear, including gloves and safety glasses. If unsure, consult a qualified mechanic.

This detailed guide will help you confidently identify a Dana 60 front axle, whether you’re inspecting a vehicle for purchase, working on a restoration project, or simply curious about this iconic heavy-duty axle. Remember that meticulous observation and cross-referencing of your findings are key to accurate identification.
